Atom PS-588 Manual Traveling Head Cutting Press

Atom PS-588 Manual Traveling Head Cutting Press

description1
Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Features
It's used to cut one layer or multilayer of leather, rubber, plastic, hard papers, chemical fiber etc.

1.Gantry frame structure is adopted, with high intensity and without deformation.

2.The punch head can automatically move horizontally, with excellent operating visual field and safe and reliable operation.

3.The lifting position of pressing board can be freely set to reduce idle travel and enhance work efficiency.

4.The movement of punch head is controlled by automatic speed variation to realize flexible movement with accurate positioning and without impact.

5.Differential oil way is adopted to allow rapid and convenient cutting.
Technical Parameter

Max. Cutting Pressure

25T

Stroke adjustment

5- 150mm

Size of Worktable

2000*500mm

Length × Width × Height

2760*500*2300mm

Travel Head Size

500*500mm

Motor Power

2.2kw

The Weight

2000kg
